Contextual Fit

Adding to an Existing Order

This project applied an addition to the famous Smith House that was designed in 1965 by Architect Richard Meier. The objective was to add a new system of rooms and spaces without interfering with the concept of the original design.


Narrative

Rick and Linda are newlyweds thinking of purchasing a beach home for their summer vacations. They were interested in the property but wanted an addition. They mentioned that they wanted an incorporation of a stingray into their addition as it represented the first time they met each other at work as marine biologists. Since they prioritize comfort and rest, they requested for the main focus to be the master suite. In this suite, they wanted the main focus to be the master bedroom.

Meta Idea: Stingray

Hierarchy: Master Bedroom


Sorting of Spaces

Public

  • Family Room

  • Formal Outdoor Area

  • Exercise Room

Private

  • Master Bedroom

  • Master Bathroom

Noisy

  • Family Room

  • Formal Outdoor Area

  • Exericse Room

Quiet

  • Master Bedroom

  • Master Bathroom

Action

  • Exercise Room

  • Formal Outdoor Area

​​

Rest

  • Family Room

  • Master Bedroom

  • Master Bathroom

Group

  • Family Room

  • Formal Outdoor Area

  • Exercise Room

Individual

  • Master Bedroom

  • Master Bathroom


Existing Floor Plans


Contextual Analysis

Screenshot 2023-11-13 015233.png

New Floor Plan Analysis

Screenshot 2023-11-15 175258.png

Hierarchy

Screenshot 2023-11-15 192812.png

Circulation

Screenshot 2023-11-15 175244.png

Bearing Wall

Girder

Column

Screenshot 2023-11-15 175815.png

Outdoor

Indoor

Screenshot 2023-11-16 003607.png
Screenshot 2023-11-16 012932.png

Lower Level

Entry Level

Master Bathroom

Walk-In Closet

Storage

Opening to
Master Bedroom

Outdoor Deck

Exercise Room

Floor Plans

Lower Patio

Bedroom

Dining Room

Kitchen

Bath

Master Bathroom

Living Room

Open to Below

Clo.

Bath

Bedroom

Upper Patio

Screenshot 2023-11-16 022104.png

Upper Level

Family Room

Open to Living Room

Bedroom

Bedroom

Bath

Office

Open to Deck

Bedroom

Site Plan

Screenshot 2023-11-13 025809.png

Elevations

Screenshot (5).png
Screenshot (11).png
Screenshot (6).png

North Elevation

East Elevation

Screenshot (9).png

South Elevation

West Elevation

Sections

Screenshot 2023-11-15 193555.png
Screenshot 2023-11-15 193408.png

Section 1

Section 2

Screenshot 2023-11-15 200051.png

3D Section 1

Screenshot 2023-11-15 200202.png

3D Section 2

Preliminary Design

Screenshot 2023-11-13 024547.png

Final Design

Screenshot 2023-11-13 025423.png
Screenshot 2023-11-13 025444.png

Transformation Process


Exterior Renders

Screenshot 2023-11-15 212507.png
Screenshot 2023-11-15 212804.png
Screenshot 2023-11-15 212638.png

Interior Renders
